Main function

Printing speed: lOOmm/s ( 8.5v-12v input voltage)

200mm/s (24vinput voltage)

Printing life: 1 million line characters

Cutter life: I million times (full/part by option)

Paper feed direction: 1800 hor:izontal feeding, paper easy loading.

Paper: :58mm width thermal paper (0.06-O.lOmm thickness)

Interface: RS-232/USB ( by option)

Special features

1. ALL-IN-ONE design: this type embedded printer precisely integrates control board; cutter and outside installation structure, it completely solves customer a series of problems including hard installation; complex designing; long-term operating, etc. this one can directly applies to customers' instruments or equipments

2. Unique paper holder: it provides more convenience for customer for paper installation ( 80-140 mm diameter roll by option)

3. High speed: printing speed can arrive at 200mm/s(max), in normal condition it can reach 170mm/s

4. Excellent reliability: whole mechanism using life has been extended commendably, the easier loading paper and paper jam prevention performance will do better favor for user

5. Interface diversification: RS-232/TTL/USB by option, and provides comprehensive software instructions and the concise driver ( winxp/win7)

Application:

Self-service instrument (discount coupon kiosk, bank call distributor, parking card-delivery machine, telephone bill payment machine etc.)
